Keep Me Updated, OK? Oct 6, 2023 We’ve already explored API List operations in depth in What Am I Getting Out of This? We also covered how to Create new resources in Getting Creative with OpenAPI. Next, let’s explore the many API design matters of Updating resources. Welcome to the next article in The Language of API Design series. Rather than jumping into the middle of this series, I encourage new visitors start by reading The Language of API Design and scanning previous posts in the series. Updating API Resources with the PUT Method While PUT is a conventional way to implement the Update operation in a CRUDL pattern, relying to heavily on CRUDL is perilous. The HTTP specification establishes the semantics of the PUT method. Notably: The PUT method requests that the state of the target resource be created or replaced with the state defined by the representation enclosed in the request message content. A successful PUT of a given representation would suggest that a subsequent GET on that same target resource will result in an equivalent representation being sent in a 200 (OK) response. This is an important distinction. If an object has optional properties, such that a Read (GET) operation may omit some values based on the state of the application, then omitting those values in a PUT request should be interpreted as a request to reset those values to an omitted state, not simply a request to skip updating those properties. Thus, APIs should avoid using PUT to perform partial updates of a resource. A partial update assigns only the fields that are present in the request and does not update any properties not present in the request. Using PUT for partial updates breaks the implicit and accepted understanding of HTTP PUT’s semantics, which can confuse your API consumers who expect consistency across API providers. Using PATCH for API Updates An alternative to using PUT is to use the PATCH method. Although PATCH is not officially part of the HTTP specification—it is defined by its own RFC—the HTTP specification does reference it: Partial resource updates are also possible […] by using a different method that has been specifically defined for partial updates (for example, the PATCH method defined in [RFC5789) JSON Merge Patch (RFC 7386) is a standard that defines a set of semantics for PATCH. There are other standards, such as JSON Patch, that define alternative semantics for PATCH. JSON Patch is a language of its own, and it requires complex implementation support. By contrast, JSON Merge Patch has only three behaviors: A named non-null value in the request replaces the same named value in the target resource. A named null value unsets or removes a named value in the target resource. Any value not named in the request is left unchanged in the target resource. Here is the definition of the patchUniverse operation, which allows the client to specify the request body is using JSON Merge Patch by using the application/merge-patch+json content type or just application/json. paths: /universes/{universeId}: parameters: - $ref: '#/components/parameters/universeIdPathParam' patch: summary: Patch a Universe instance. description: >- Update the mutable properties a Chain Link Universe instance. This update follows [JSON Merge Patch](http://datatracker.ietf.org/doc/html/rfc7386) semantics. operationId: patchUniverse tags: - Universes requestBody: description: Mutable properties of the universe to be updated. content: application/merge-patch+json: schema: $ref: '#/components/schemas/universePatch' application/json: schema: $ref: '#/components/schemas/universePatch' responses: '200': description: OK. The operation succeeded. content: application/json: schema: $ref: '#/components/schemas/universe' '400': $ref: 'common.yaml#/components/responses/400' '404': $ref: 'common.yaml#/components/responses/404' (The cited common.yaml file is defined here. The universePatch schema is defined below.) The Update operation is expressed with an OpenAPI operation object with one path parameter, denoted here by {universeId}. A path parameter lets you define an API URL path element that varies from call to call; the parameter is a placeholder for the value of that varying path element. The parameter {universeId} is replaced with the id value of a specific Universe instance. Path parameters are defined with a parameter object in the OpenAPI Specification. Each OpenAPI parameter has the following properties: a name ("universeId" in this example) a required in property. For path parameters, the value of the in property is always path. The in property may also have the value header, query, or cookie for those type of operation parameters. a description a flag to indicate if the parameter is required. This must always be true for path parameters. a schema to define the parameter’s valid values (JSON Schema data type and constraints). OpenAPI allows you to define the path parameter at either the path level (shared among all operations defined for that path), or at the operation level. We use a $ref to reference a parameter component. OpenAPI uses a parameters array, since a path or operation can have multiple parameters. To define parameters at the path level, we nest the parameters beneath the path 1/universes/{universeId}1 as a sibling object of the patch operation: paths: /universes/{universeId}: parameters: - $ref: '#/components/parameters/universeIdPathParam' patch: .... components: parameters: universeIdPathParam: name: universeId description: The unique `id` of an existing Universe instance. in: path required: true schema: type: string minLength: 4 maxLength: 48 pattern: ^[-_a-zA-Z0-9:+$]{4,48}$ At the operation level: paths: /universes/{universeId}: patch: .... parameters: - $ref: '#/components/parameters/universeIdPathParam' I prefer the former for path parameters since it is easier to add other operations (such as a delete) that share the same path parameters. This way, all operations defined within the path use the same definition for the {universeId} path parameter, keeping the API definition DRY. Finally, the 200 OK response uses the universe schema so that the client receives the updated state of the resource, including any derived properties. By returning the full representation, the client does not need to make another API call to the Read (GET) operation. Modeling the Update Operations’ Request Body Keeping in mind that REST is the exchange of representations of resources and application state, an Update is an operation that passes a representation of the resource in the request body. The JSON representation of our Universe resource may look like the following, as defined by a universe schema and returned by the Read and Create operations: { "id": "uni-489f34dhj37sghj", "name": "DragonTerr", "description": "A world where dragons rule", "createdAt": "2023-08-23T18:34:10.444Z", "creator_url": "/authors/au-ndklxhjf8933x0", "characters_url": "/characters?universe=uni-489f34dhj37sghj", "chains_url": "/chains?universe=uni-489f34dhj37sghj" } However, several (most!) of these properties are derived and immutable, and thus unnecessary in the update request body. This is a fairly common situation. One way to code for this in OpenAPI is to mark the immutable properties as readOnly: true in their JSON Schema. The OpenAPI Specification (version 3.0) says of readOnly: true : Declares the property as “read only”. This means that it MAY be sent as part of a response but SHOULD NOT be sent as part of the request. If the property is marked as readOnly being true and is in the required list, the required will take effect on the response only. A property MUST NOT be marked as both readOnly and writeOnly being true. Default value is false. However, since OpenAPI 3.1 relies on JSON Schema, OAS 3.1 is now silent on readOnly. JSON Schema says of the readOnly keyword: If "readOnly" has a value of boolean true, it indicates that the value of the instance is managed exclusively by the owning authority, and attempts by an application to modify the value of this property are expected to be ignored or rejected by that owning authority. Thus, the service behind the API (the “owning authority”) must be careful to not update the value of read-only properties when updating the subsequent representation of the resource (normally by not updating the application storage of the resource). Indeed, improper adherence to the readOnly: true constraint is a common API security vulnerability, described by API3:2023 Broken Object Property Level Authorization in the OWASP API Security Top Ten vulnerabilities (formerly API6:2019 - Mass Assignment in the 2019 OWASP API Security Top Ten). A better option (in my opinion) is to limit the properties the client is allowed to send, employing a more restrictive update schema: one which does not include any readOnly properties. Throw in unevaluatedProperties: false while you’re at it. For a Universe instance, we only wish to allow updating the name and description properties. We can use a JSON schema with only those two mutable properties. Using some of the techniques for schema composition presented in Composing API Models with JSON Schema, we can define those two properties in one mutableUniverseFields schema, then reuse those properties to refactor the universe schema presented earlier and our new universePatch schema for the patchUniverse operation. components: schemas: mutableUniverseFields: title: Mutable Universe Fields description: Mutable properties of a Chain Link universe instance. properties: name: description: The name of the universe. minLength: 4 maxLength: 64 description: description: The description of the universe. minLength: 4 maxLength: 512 universe: title: Universe description: >- A universe in which authors can create new characters and new chains. type: object required: - id - name - description - createdAt - creator_url - characters_url - chains_url unevaluatedProperties: false allOf: - $ref: '#/components/schemas/mutableUniverseFields' - type: object properties: id: $ref: 'common.yaml#/components/schemas/resourceId' sourceUniverse_url: description: >- An optional universe that this one is derived from. type: string format: uri_reference createdAt: description: >- The date and time the author created universe, in RFC 3339 date-time format. type: string format: date-time creator_url: description: The URL of this universe's creator/author. type: string format: uri-reference characters_url: description: >- The URL of the API operation to list the characters that exist in this universe. type: string format: uri-reference chains_url: description: >- The URL of the API operation to list the chains that exist in this universe. type: string format: uri-reference universePatch: title: Universe Patch description: >- Request body for updating the mutable properties of a Chain Link universe instance. type: object unevaluatedProperties: false allOf: - $ref: '#/components/schemas/mutableUniverseFields' Note that type constraints in the name and description properties do not include JSON Schema’s null type (as described in Master More JSON Schema’s Subtleties) because this API does not support removing (unsetting) a universe’s name or description. Even though JSON Merge Patch allows using a null to remove a property from a target resource, the JSON Schema type constraints on these properties of a Universe prohibits that. Below are four valid examples for the universePatch schema: an empty request, updating just the name, updating just the description, or updating both: { } { "name": "DragonTerr" } { "description": "A world where dragons rule." } { "name": "Dragon-Terr", "description": "A world where dragons rule." } Avoiding API Abuse Earlier I mentioned some perils of using the CRUDL pattern for APIs. As described at the beginning of this series, the best APIs arise when they closely map to and implement behaviors that the clients need, rather that be derived from or reveal back-end implementation details (such as SQL and database schemas). A CRUDL API is an closer to the latter. The most severe CRUDL peril lies in casting all client behaviors in the CRUDL mold. For example, an API for a vehicle may include the vehicle’s speed in the Read response. If thinking only in terms of CRUDL, one may treat the speed property as mutable within a general vehicle update operation, passing it among other mutable properties as one way to stop a moving vehicle: PUT /vehicles/{vehicleId} { ..., "speed": 0, ... } This is a somewhat circuitous way to “stop” the vehicle, analogous to manually moving an mechanical speedometer to 0 to stop the car rather than using the brake. Manu vehicles let on adjust the spee cruise control by incrementing or decrementing the speed in units. Stopping a car traveling 30 MPH would require 30 button pushes‐ not a great user interface, and ptentially disasterous in a vehicle emergency. Photo credit Brian Snelson from Hockley, Essex, England - Speedometer, CC BY 2.0 API operations should be atomic: do one thing and do that one thing well. If operations have multiple unrelated behaviors attached to them, the API becomes very complex and hard to reason about for both consumers and implementors. Such undue complexity increases by an order of magnitude if the resource’s Read representation contains nested objects. Mixing updates of the resource along with updates to nested objects leads to a confusing API, and one that is hard to evolve as new properties are added over time (which will almost always happen). Instead, consider using POST operations to issue commands or to apply actions to resources to implement independent behaviors in the application’s domain. For example, one can define a publishChain operation that applies to a Chain instance to publish them POST /chains/{chainId}/published The publishChain operation can implement all the behaviors necessary to publish the Chain, the smallest of which is updating the chain.published status to true (which is then available in the publishChain operation response, which is symmetric with the Read response.) Such designs make the API’s intent clearer—there is a specific operation dedicated to each behavior in the domain, rather than blending many behaviors into a single “do everything” operation that gets more complex and more fragile as the API evolves. Especially when one considers a Software Development Kit that you may generate from the OpenAPI definition, the benefits of such intention-revealing operations become even clearer. For example, there will be a publishChain() function in the SDK. As a result, both the SDK and the API become more self-descriptive. Today’s lesson ends with this warning against an creating an API that is (to paraphrase the words of Brian Foote and Joseph Yoder in Big Ball of Mud) “dictated more by expediency than design”. CRUDL may seem like an easy pattern, but tread lightly when tempted to (over) use it. Join the discussion Note: This article was originally published on the auhor’s API Design Matters Substack.
